Side panel with audio elements for Totem Mini Lab and Totem Micro Lab sets. The board has an audio amplifier with a loudspeaker, a VU indicator, a function generator and a pi filter circuit. Totem TE-SP03-B

4 weeks
Awaiting delivery
Kamami is the official distributor of Totem Maker construction sets. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The Totem Audio Side Panel is a side panel designed for the Totem Mini Lab and Totem Micro Lab kits.It serves as a module that extends the capabilities of the basic package with audio components such as an amplifier with a loudspeaker, VU (volume unit) indicator, a function generator (sine, square and triangle waves) and a pi filter prototyping area. The board has a connector for each of the elements, so that the user can connect them in a convenient way using wires. The kit includes all the mechanical components and tools necessary to attach the side panel to the laboratory structure. In the GitLab repository there are sample projects using the Totem Audio Side Panel.

Features

  • Class AB amplifier with loudspeaker
  • VU (volume unit) indicator with 10-element LED display, 3dB / step, up to 30 dB
  • Function generator (sine, square and triangular waves) up to 12.5 MHz
  • Pi filter prototyping area
  • Easy to mount to the lab frame

Kit contains

  • Audio side panel
  • Clamping beam
  • 2 x Nylon spacer
  • 2 x Screw
  • 2 x Nut
584647
