Cooling Fan XU4 Blue - wentylator do Odroida XU4 - niebieski
search
  • Cooling Fan XU4 Blue - wentylator do Odroida XU4 - niebieski
ID: 562769
5906623437160
zł38.81
Tax included

zł31.55 tax excl.

  1. The ODROID-XU4 includes the cooling fan by default. You might need this part when you want to replace the original cooling fan
24h
Available
Available quantity: 2
Kamami is the official distributor of Odroid computers and accessories. All products of this brand in our offer are original and come directly from the manufacturer.

Description

The ODROID-XU4 includes the cooling fan by default. You might need this part when you want to replace the original cooling fan.

Features

  • Power : 5Volt / 120mA(max)
  • Dimension : 39.5 x 40.0 x 10.0 mm
  • Fan speed : 4000rpm approx.
  • Cable length : 50mm approx.
  • Noise Level : 23dBA approx.
  • Blue anodizing surface

Note: Package includes a thermal paste tube. The thermal paste is responsible for conducting heat from the processor to the heat sink. Reassembling without applying thermal paste will cause the processor to overheat.

PWM port on ODROID-XU4 2pin header which connector is Molex 51021-0200 / 1.25mm pitch.
The fan motor speed is controlled by CPU temperature proportionally. Thermal interface material (double-side tape) is assembled.

Installation Guide:

  • Step 1 : Remove the stock cooling fan
  • Step 2 : Clear the surface of the CPU and cooling fan
  • Step 3 : Apply the thermal paste on the CPU surface. Make sure to cover the entire surface that will mate to the cooler.
  • Step 4 : Install the new cooling fan

Cautions! Minimize stress/bending to the PCB when you mount/un-mount the cooler

562769

Data sheet

Voltage
5 V
Power
0,6 W
Length
39,5 mm
Width
40mm
Height
10
Weight
Other
Noise level
23 dBA
Air flow efficiency
Other
Rated current
120 mA
Fan type
Axial
