Evaluation board with a Raspberry Pi RP2040 microcontroller and a TCP/IP W5500 controller. WIZnet W5500-EVB-PICO

24h
Available
Available quantity: 116
Kamami is the official distributor of WIZnet network modules for Raspberry Pi Pico. All products of this brand in our offer are original and come directly from the manufacturer.

Description

Evaluation board with a Raspberry Pi RP2040 microcontroller and a TCP / IP W5500 controller. The RP2040 system is equipped with two ARM Cortex M0 + cores operating at a frequency of 133 MHz, 264 KB of RAM and 30 GPIO ports. The microcontroller itself is not equipped with flash memory, but on the board there is an external memory with a capacity of 2 MB connected via the QSPI interface. The platform supports the popular MicroPython and C / C ++ programming languages. Programs can be uploaded to memory via the USB interface in mass storage mode or by using an external programmer that supports the SWD interface. The W5500 Ethernet network module communicates via the SPI interface, has a built-in TCP / IP stack, and supports protocols such as TCP / IP, UDP, ICMP, ARP, IGMP, PPPoE. It supports Wake on LAN over UDP and supports up to 8 independent sockets simultaneously.

Features

  • RP2040 microcontroller with 2 MB Flash memory
    • Two ARM COrtex-M0 + cores with a frequency of up to 133 MHz
    • 264 kB of SRAM
    • Quad-SPI external flash memory with eXecute In Place (XIP) function
    • 30 multi-functional general purpose IOs (4 can be used for ADC)
    • I / O voltage 3.3 V
    • 12-bit 500ksps analog-to-digital converter (ADC)
    • 2 × UART, 2 × I2C, 2 × SPI, 16 × PWM channels
    • 1 × Timer with 4 alarms, 1 × Real-time counter
    • 2 × programmable IO blocks (PIO)
    • Flexible, user-programmable high-speed IO
    • It can emulate interfaces such as SD card and VGA
  • W5500 chip
    • Supports wired internet protocols: TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE
    • Supports 8 independent hardware sockets simultaneously
    • 32 KB internal memory for TX / RX buffers
    • Supports high-speed peripheral interface (SPI mode 0, 3)
  • Micro-USB B port for power and data transfer (and for flash reprogramming)
  • 3-pin Serial Wire Debug (SWD) port
  • Built-in 10/100 Ethernet PHY
  • RJ45 connector
  • Built-in LDO
1180932

Data sheet

Microcontroller
RP2040
Flash memory
Brak
Number of I/O
30
Ethernet
100Mb x1
WiFi/BT module
No
Bluetooth module
No
MicroSD slot
No
USB connector type
microUSB type B
